Structurizr Theme Customization

Archlette supports Structurizr themes to customize the visual appearance of your architecture diagrams.

Default Theme

By default, Archlette uses a professional blue gradient theme:

  • Systems: Dark blue (#1168bd)
  • Containers: Medium blue (#438dd5)
  • Components: Light blue (#85bbf0)
  • Cloudflare Workers: Orange highlight (#f6821f)
  • Actors: Person shapes with distinct styling
  • External Systems: Gray (#999999)

Custom Themes

You can override the default theme by providing a custom Structurizr theme DSL file.

Configuration

In your archlette.config.yaml:

generators:
  - use: generators/builtin/structurizr
    inputs:
      theme: path/to/custom-theme.dsl

Path Resolution: Theme paths are resolved relative to your config file location. This allows you to keep themes alongside your configuration.

Examples:

# Relative to config file (recommended)
theme: themes/custom.dsl           # ./themes/custom.dsl from config location
theme: ../shared-themes/dark.dsl   # shared themes in parent directory

# Absolute paths
theme: /opt/company/themes/brand.dsl

# Home directory
theme: ~/archlette-themes/custom.dsl

Theme File Format

A theme file is a Structurizr DSL file containing style definitions. Example:

/**
 * Custom Dark Mode Theme
 */

theme default

styles {
    // Person/Actor styles
    element "Person" {
        background #2c3e50
        color #ecf0f1
        shape Person
        fontSize 22
    }

    // System styles
    element "Software System" {
        background #34495e
        color #ecf0f1
        shape RoundedBox
        fontSize 22
    }

    // Container styles
    element "Container" {
        background #7f8c8d
        color #ecf0f1
        shape RoundedBox
        fontSize 20
    }

    // Component styles
    element "Component" {
        background #95a5a6
        color #2c3e50
        shape RoundedBox
        fontSize 18
    }

    // Relationship styles
    relationship "Relationship" {
        routing Curved
        fontSize 18
    }
}

Element Tags

You can style elements with specific tags:

  • Person - Human actors in the system
  • Software System - System-level components
  • Container - Application/service containers
  • Component - Code components
  • External System - External dependencies
  • Cloudflare Worker - Cloudflare Worker containers

Available Properties

Element Styles

  • background - Background color (hex)
  • color - Text color (hex)
  • shape - Visual shape (Person, RoundedBox, Box, Cylinder, etc.)
  • fontSize - Text size in points
  • border - Border style

Relationship Styles

  • routing - Line routing (Direct, Curved, Orthogonal)
  • fontSize - Label text size
  • thickness - Line thickness
  • color - Line color
  • dashed - Whether to use dashed lines (true/false)

Fallback Behavior

If a custom theme file is not found at the specified path, Archlette will:

  1. Log a warning message
  2. Fall back to the default theme
  3. Continue processing without errors

Examples

Dark Mode Theme

See custom-theme-test.dsl for a complete dark mode example with:

  • Dark backgrounds (#2c3e50, #34495e)
  • Light text (#ecf0f1)
  • Muted accent colors (#7f8c8d, #95a5a6)

Brand Colors

You can create themes matching your company brand:

element "Software System" {
    background #FF6B35  // Brand orange
    color #FFFFFF
}

element "Container" {
    background #004E89  // Brand blue
    color #FFFFFF
}

Best Practices

  1. Color Accessibility: Ensure sufficient contrast between text and backgrounds
  2. Consistency: Use a cohesive color palette across all element types
  3. Hierarchy: Use color intensity to show architectural hierarchy (dark systems → light components)
  4. External Distinction: Style external systems differently to show boundaries
  5. Actor Visibility: Use Person shapes and distinct colors for human actors
